Built-in Test Diagnostics
Microcontroller self-test vacuum sensor validation power-up Continuous vacuum system monitoring to ensure optimum operational conditions are maintained Vacuum system fault detection and shutdown function indicators
Teflon AF Membrane
Flow-through vacuum degassing chamber with a single amorphous perfluorinated copolymer degassing membrane (Teflon AF), enabling degassing efficiency 50 times that of PTFE.
Continueous Run Vacuum Pump
Continueous Run Vacuum Pump employs a closed-loop, microstepping RPM control strategy permitting the pump to run with continuously variable speed, providing quick pull-down at high RPM, and then sustaining a consistent vacuum level at low RPM.
Fluctuations in detector baseline due to changes in vacuum level are eliminated by not having to repeatedly stop and start a singlespeed pump. This also greatly reduces wear and noise.
Validation Output
The validation output records vacuum level to compile ISO and system validation requirement.
